Description
The 3050-100 series microscope features a modern design with a convenient handle on the arm of the microscope, for an easy and safe transfer from one workspace to another. It features a built-in mechanical stage, 1.25 NA Abbe condenser and an iris diaphragm. Comes with a 5 year limited warranty.
| ITEM NO. | HEAD | EYEPIECE | OBJECTIVES | ILLUMINATION |
| 3050-100-LED | Monocular | 10x WF | 4x, 10x, 40xR, 100xR | LED Corded |
| 3050-100-RC | Monocular | 10x WF | 4x, 10x, 40xR, 100xR | LED Cordless |
| 3050-T-100-LED | 45° Dual View | 10x WF | 4x, 10x, 40xR, 100xR | LED Corded |
| 3050-T-100-RC | 45° Dual View | 10x WF | 4x, 10x, 40xR, 100xR | LED Cordless |
Specifications
| Model | 3050-100-LED / 3050-100-RC | 3050-T-100-LED / 3050-T-100-RC |
| Body | All metal construction, modern design,carrying handle on arm | |
| Head |
Monocular, 45° inclined | Dual View, 45° inclined |
| Eyepiece | Locked-on 10X wide-field eyepiece with pointer (Dual view has additional 10X wide-field eyepiece) | |
| Nosepiece | Reversed, four position nosepiece with positive stop clicks | |
| Objectives | 4X, 10X, 40XR, 100XR (oil) DIN achromatic objectives are color-coded | |
| Stage | 4″ x 3.5″ double layer mechanical stage with mounted specimen holder | |
| Condenser | 1.25 N.A. Abbe condenser | |
| Diaphragm | Iris diaphragm | |
| Focusing System |
Coaxial coarse and fine focus control | |
| Illumination | LED illumination with light intensity control | |
| Power | LED: 3-wire grounded power cord RC: 3 AA NiMH batteries or AC adapter (both included) | |
| Accessories | Vinyl dust cover and user manual | |
| Warranty | Limited 5 year | |
